Standard pressure upto 6000 PSI, optional pressure upto 10000 PSI

Derline seat standard for easier replacement also available in PEEK, PTFE & KEL-F.

Non rotating vee / Ball tip design which forms a bearing joint with the stem eliminates rotation between plug & seat at closure, This prevents scoring and galling up the valve seat and ensure long life in repetitive shut off service.

Safety bonnet lock prevents accidental disassembly.

Stem thread rolled & hard plated for additional strength & maximum service life.

Adjustable packing below stem threads prevents stem lubrication washout and isolate threads from process contamination.

Safety back seating provides secondary stem seal in full open position, prevents stem blow out.

Body to bonnet seal metal to metal constant compression, isolate bonnet threads from system fluids and eliminates possible tensile.

Panel Mounting Option Available
